RTDS123C high-performance ceramic packaged LWIR sensor

Name: RTDS123C high-performance ceramic packaged LWIR sensor
Brand: Shanghai Everay Optical Electronics Technology Co., Ltd.

RTDS123C is a ceramic-packaged LWIR sensor (1280×1024, 12μm) based on vanadium oxide (VOx) microbolometer with an 8-14 µm wavelength range, high-quality images with high performance and high sensitivity. RTDS123C applies to multiple scenarios, e.g. industrial temperature measurement, outdoor night vision, etc.

Get a Quote

Specifications

Item	Specification
Model	RTDS123
Sensor Technology	VOx microbolometer
Spectral Range	8-14μm
Pixel Pitch	12μm
Array Format	1280×1024
Output Format	14bits(25/30Hz) 13bits（50Hz）
Read Mode	Rolling shutter mode
mirroring	X-mirroring, Y- mirroring
Operability	≥99.5%
Non-uniformity Correction	On-chip 6-bit non-uniformity correction
Frame Rate	25/30/50 Hz
Operating Temperature Range	-40~+85℃
Thermal Time Constant	<15 ms
NETD	<40 mK (f/1.0, 30Hz, 300K)
Power Consumption	<300 mW (30Hz, 25℃)
Package Type	56-Pin Ceramic
Size	27×27×4.6 mm³
Weight	≤10 g
