YL320V OGI Optical Gas Imaging Cameras

YL320V optical gas imaging cameras is a cooled IR imaging detector that specialized in VOCs gas leak detection such as methane.

This ogi camera product uses a MWIR detector based on quantum wells (QWIP) technology with high sensitivity, enables real-time visual detection of imperceptible tiny leaks during gas production, transportation and use.

The user-friendly design of YL320V optical gas imaging cameras makes it easy to carry and operate. Optical gas imaging cameras can quickly scan potential leakage points at a safe distance, thereby reducing economic losses effectively.

Specifications of OGI Camera YL320V

Detector and lens



Pixel pitch




Working spectrum



Standard 24°×19°/optional 14.5°×11.6°


Electric focus, auto/manual focus



Chargeable lithium-ion polymer battery

continuously working≥3h@25℃

External charge


Start-up time

Room temperature ≤7min





≤310×175×150mm( including)


Working temp & humidity


Storage temp




IP rating


Temperature measurement

Measure range


Measure accuracy

±2℃ or ±2% (absolute maximum)

Measure analysis

Point/area/line/Isotherm/temperature difference analysis

Image display


5" HD touch screen LCD/LED

Visible camera

CMOS/auto focus/built-in LED fill light

Gas enhancement

Gas Visual Enhancement Mode(GVE™)

Image mode

Image enhancement/IR image/visible image/Fusion/PIP

Detectable gas

Methane, Ethane, Propane, Butane, Ethylene, Propylene, Benzene, Ethanol, Ethylbenzene, Heptane, Hexane, Isoprene, Methanol, MEK, MIBK, Octane, Pentane, 1-Pentene, Toluene, Xylene

Data storage

Storage card

32G TF card, dassl0or higher (expandable to128G)



Image format

JPEG, Includes digital photos and full radiometric data

Video storage

Radiometric/H.264 non-radiative infrared/H.264 visible light video

Features of OGI Camera YL320V

  • Leakage quick location

  • Contactless long-distance detection

  • VOCs manage assistant

  • Unreachable point detection

  • LDAR essential tool

Applications of YL320V optical gas imaging cameras

Everay YL320V optical gas imaging cameras offer versatile applications in industrial settings, contributing to enhanced safety, efficiency, and regulatory compliance. The advanced gas infrared camera plays a pivotal role in industrial gas detection, swiftly identifying various gases like hydrocarbons and methane. This capability ensures the secure operation of industrial equipment, safeguarding both personnel and assets.

One notable application is leak detection, where Everay's OGI cameras provide a non-contact method for detecting leaks, particularly in hazardous or challenging-to-access areas. Operating from a safe distance minimizes safety risks and facilitates prompt intervention.

The gas visualization feature utilizes thermal infrared cameras with unique spectral filtering methods to visualize gases like methane, aiding in the timely detection of potential issues. Additionally, handheld OGI cameras, enable rapid scanning of extensive areas and long-distance detection, ensuring operator safety.

By employing Everay YL320V cameras for leak detection, businesses can adhere to regulatory requirements, reduce operational costs, and elevate job safety standards. Overall, the versatile applications of these optical gas imaging cameras make them indispensable tools in diverse industrial environments.
